Overview
State-of-the-art 5-axis robotic gantry laser cutting machine designed for thermoformed 3D curved parts, automotive trim, and aerospace structural components.
Key Advantages
This equipment incorporates advanced industrial-grade optics and heavy-duty mechanical engineering, offering the following key advantages:
RTCP 5-Axis Simultaneous Motion: Continuous rotating C-axis (±360°) and tilting A-axis (±135°) maintain laser beam perpendicular to curved 3D contours
Gantry Dual-Drive Architecture: High-rigidity bridge gantry with high-speed AC servo motors for high-dynamic complex path tracking
Collision Protection Sensor: High-sensitivity capacitive 3D cutting nozzle stops motion in milliseconds upon unintended workpiece contact
CAM Software Integration: Native compatibility with UG NX, Mastercam, and CATIA 3D surface toolpath post-processing
[Factory Live] CW-3W1280 5-Axis Multi-Linkage 3D Laser Cutting Machine Industrial Laser System
Sample Gallery
High-precision test samples processed by this machine:
Cast Acrylic Sheet Precision Edge Cutting
Mirror-polished 90-degree edge finish straight off the machine without secondary flame polishing.
Hardwood & Architectural Plywood Complex Contouring
Ultra-narrow kerf width, sharp corner definition, and minimal thermal discoloration.
Flexible Garment Fabric & Leather Automated Nesting
Clean sealed edges without fraying, high repeat accuracy across multi-layer stacks.
Composite Die-Board & Gasket Precision Cutting
Perpendicular vertical kerf channels ensuring tight friction-fit tooling.
Technical Specifications
* Note: Parameters listed are standard factory configurations. Custom engineering and automated production line integrations are available upon request.
Applicable Materials & Industries
❖ Applicable Materials
Hot-Stamped High-Strength Steel Hydroformed Metal Tubes Thermoformed Carbon Fiber & GFRP Blow-Molded Automotive Plastics Formed Titanium & Nickel Alloys
❖ Target Industries
Automotive Thermoformed Part Trimming Aerospace Structural Panels Medical Orthopedic Implants Specialized Sheet Metal Fabrication Robotics & Defense Equipment
Request a Quote & Testing
Schedule Free Sample Testing and Engineering Consultation for CW-3W1280 5-Axis Multi-Linkage 3D Laser Cutting Machine
Our industrial laser application laboratory is equipped with high-magnification optical inspection instruments. We provide customized microscopic edge analysis reports, cycle time estimates, and competitive turnkey equipment quotes within 24 hours.
